Product Model
|
|
WH-190
|
Performance
|
|
|
Operating System
|
|
Android 8.1; Soti
MobiControl，SafeUEM supported
|
CPU
|
|
Cortex-A53 2.5 GHz Octa-core
|
RAM+ROM
|
|
3 GB + 32 GB / 4 GB + 64 GB (Optional)
|
Expansion
|
|
Supports up to 128 GB Micro SD
card
|
Physical Characteristics
|
|
|
Dimensions
|
|
164.2 × 80.0 × 24.3 mm / 6.46 × 3.15 × 0.96 in.
|
Weigh
|
|
654 g / 23.07 oz.
|
Display
|
|
5.2'' IPS FHD 1920 × 1080
|
|
Touch Screen
|
|
Corning Gorilla
Glass，multi-touch panel，gloves
|
|
|
and wet hands supported
|
Battery Capacity
|
|
Li-ion / Rechargeable / 8000 mAh
|
Standby
|
|
Over 500 hours
|
Continuous Use
|
|
Over 12 hours (depending on user
environment)
|
Charging Time
|
|
3-4 hours (with standard adaptor
and USB cable)
|
Expansion Slot
|
|
1 slot for SIM card，1 slot for
SIM or TF card
|
Interfaces
|
|
USB 2.0 Type-C，OTG，Type-C
headphones supported
|
Audio
|
|
Speaker，2 microphones
|
|
Keypad
|
|
4 front keys，1 power key，2 scan
keys，
|
|
|
1 multifunctional key
|
Sensors
|
|
Gravity sensor，light
sensor，proximity sensor
|
Communication
|
|
|
|
WLAN
|
|
IEEE802.11 a/b/g/n/ac，2.4G/5G
dual-band，
|
|
|
Internal Antenna
|
|
|
|
2G： 900/1800MHz
|
|
|
|
3G： WCDMA：B1/B8
|
|
WWAN (China)
|
|
CDMA2000 EVDO：BC0
|
|
|
|
TD-SCDMA：B34/B39
|
|
|
4G： B1/B3/B5/B8/B34/B38/B39/B40/B41
|
|
|
|
2G： 850/900/1800/1900 MHz
|
|
WWAN (Overseas)
|
|
3G： B1/B2/B4/B5/B8
|
|
|
4G： B1/B2/B3/B4/B5/B7/B8/B12/B17/B20/B25/B40/B66
|
Bluetooth
|
|
Bluetooth v2.1+EDR， 3.0+HS，
v4.1+HS
|
GNSS
|
|
GPS/AGPS， GLONASS， BeiDou;
internal antenna
|
Barcode Scanning
|
|
(Optional)
|
1D Linear Scanner
|
|
(Optional)
|
|
|
|
UPC/EAN， Code128， Code39，
Code93， Code11，
|
|
1D Symbologies
|
|
Interleaved 2 of 5， Discrete 2
of 5， Chinese 2 of 5，
|
|
|
Codabar， MSI， RSS，etc.
|
2D Linear Scanner
|
|
(Optional)
|
|
|
|
PDF417， MicroPDF417， Composite，
RSS， TLC-39，
|
|
|
|
Datamatrix， QR code， Micro QR
code， Aztec，
|
|
2D Symbologies
|
|
MaxiCode; Postal Codes： US
PostNet， US Planet，
|
|
|
|
UK Postal， Australian Postal，
Japan Postal，
|
|
|
Dutch Postal
(KIX)，etc.
|
UHF RFID
|
|
(Optional)
|
Engine
|
|
CM2000-1 module based on Impinj
Indy R2000;
|
Frequency
|
|
865-868 MHz / 920-925 MHz /
902-928 MHz
|
Protocol
|
|
EPC C1 GEN2 / ISO18000-6C
|
Power
|
|
1 W (30 dBm，+5dBm to +30 dBm
adjustable)
|
R/W Range
|
|
Up to 15 m (circular
polarization)
|
Fastest Read Rate
|
|
900+ tags/sec (circular
polarization)
|
NFC
|
|
(Optional)
|
Frequency
|
|
13.56 MHz
|
Protocol
|
|
ISO14443A/B，ISO15693，NFC-IP1，NFC-IP2，etc.
|
Chips
|
|
M1 card (S50, S70),
CPU card, NFC tags, etc.
|
Range
|
|
2 - 4 cm
|
Graphic Collections
|
|
|
Camera
|
|
13 MP Autofocus with
flash
|
User Environment
|
|
|
Operating Temp
|
|
-20℃ to +50℃
|
Storage Temp
|
|
-40℃ to +70℃
|
Humidity
|
|
5% RH - 95% RH non condensing
|
|
Drop Specification
|
|
Multiple 1.5M dropsto the concrete across the
|
|
|
Operating temperature
range
|
Protection Grade
|
|
IP65
|
ESD
|
|
±15 KV air discharge, ±6 KV
conductive discharge
|
Developing Environment
|
|
|
SDK
|
|
Software Development
Kit
|
Language
|
|
Java
|
Tool
|
|
Eclipse / Android
Studio
|
Android 8.1 / 11.0
Cortex-A53 2.5GHz/2.3GHz八核
RAM+ROM:3GB+32GB/4GB+64GB
5.2" IPS Hd screen
8000mAh large capacity battery
UHF（ISO 18000-6C）
Barcode scanning (optional)
Full-featured NFC (optional)
Iris Scanner (optional)
13 million hd cameras
GPS
